DH9500 is listed as 7kW rated and 8kW maximum. It should be quoted as a documented compact diesel model, not described as a 10kW rated unit.
DH9500 factory model data
| Item | DH9500 specification from supplied model sheet |
|---|---|
| Rated AC voltage | 110V / 220V / 380V configuration scope, confirm final phase and voltage in the quotation. |
| Frequency / speed | 50Hz or 60Hz, 3000 rpm reference. |
| Engine type | Single-cylinder, vertical, 4-stroke air-cooled diesel engine. |
| Starting system | Electric start. |
| Noise reference | 80-85 dB at 7m on the supplied sheet; final noise expectation depends on load, site and installation. |
| Continuous work reference | 12 hours listed on the sheet; actual runtime depends on load and operating conditions. |
| Weight | 110kg net weight and 115kg gross weight. |
| Optional features | Wheels, digital meter, ATS and remote control are optional items. |
Where DH9500 may fit in Nigeria
DH9500 can be considered for shops, clinics with limited essential load, POS businesses, small offices and light work areas where the buyer needs more margin than a 6kW unit.
If the buyer has pumps, compressor motors, large refrigeration or multiple air conditioners, send nameplate information before selection. A larger set may be safer than forcing a compact model to cover starting demand.
Quote checks before payment
- Confirm exact DH9500 model and rated output in writing.
- Confirm 220V or 380V, single-phase or three-phase and 50Hz requirement.
- Confirm optional accessories and whether they affect price and packing size.
- Request current product photos and export packing details.
- Ask for FOB China and CIF Lagos scope as separate lines.
Build your DH9500 WhatsApp RFQ
Send the key configuration details so the sales team can quote the correct DH9500 scope instead of a vague compact generator price.
DH9500 FAQ
What is the DH9500 rated output?
The current factory model sheet lists DH9500 at 7kW rated output and 8kW maximum output.
How is DH9500 different from DH8500?
DH9500 has a higher listed output and uses the 192F engine reference, while DH8500 is listed with 6kW rated output and 190F engine reference.
What should a DH9500 quote include?
A useful quote should state voltage, phase, frequency, optional accessories, packing data, quantity, delivery basis and whether factory evidence can be provided before shipment.
