DH10500 is not represented as a 10kW rated generator. The supplied model sheet states 8kW rated output and 9kW maximum output. This clear boundary helps buyers avoid under-sized orders.
DH10500 factory model data
| Item | DH10500 specification from supplied model sheet |
|---|---|
| Rated AC voltage | 110V / 220V / 380V configuration scope, confirm final phase and voltage in the quotation. |
| Frequency / speed | 50Hz or 60Hz, 3000 rpm reference. |
| Engine type | Single-cylinder, vertical, 4-stroke air-cooled diesel engine. |
| Starting system | Electric start. |
| Displacement | 456cc listed on the supplied sheet. |
| Noise reference | 80-85 dB at 7m on the supplied sheet; request written test basis for noise-sensitive sites. |
| Continuous work reference | 11 hours listed on the sheet; actual runtime depends on load and operating conditions. |
| Weight | 115kg net weight and 120kg gross weight. |
| Loading reference | 102 pcs for 20FT and 204 pcs for 40HQ are listed for this model sheet entry. |
| Optional features | Wheels, digital meter, ATS and remote control are optional items. |
When DH10500 may fit in Nigeria
DH10500 may fit buyers who need an upper compact diesel option for small commercial backup, light workshop use, rural business power or dealer sample orders. It is closer to common 10kW searches, but it is still documented as 8kW rated.
If the buyer must run a pump, compressor, multiple AC units or continuous production load, send the starting load and duty cycle before selection. The better sales move is to match the real load instead of forcing the largest compact model.
Quote checks before payment
- Confirm DH10500 is quoted as 8kW rated and 9kW maximum.
- Ask for the approved datasheet before using the model for a 10kW requirement.
- Confirm 220V or 380V, single-phase or three-phase and 50Hz requirement.
- Confirm optional wheels, digital meter, ATS or remote control in writing.
- Request current model photos, packing size, gross weight and shipping term.
Build your DH10500 WhatsApp RFQ
Send enough information to confirm whether DH10500 is enough or whether a larger matched generator is safer for the site.
DH10500 FAQ
Is DH10500 a 10kW rated generator?
No. The current factory model sheet lists DH10500 as 8kW rated output and 9kW maximum output.
When should a buyer choose a larger generator than DH10500?
Choose a larger matched model when the site needs true 10kW continuous output, has significant motor starting load, or requires long-hour prime operation with more reserve.
What details are needed for a DH10500 quotation?
Send application, load list, voltage, phase, quantity, optional accessories and FOB China or CIF Lagos delivery basis.
